TC11000E3D ‌Premium Open-Frame Air-Cooled Diesel Generator

High Performance Output:
Delivers a maximum power output of 8.5kW, making it suitable for demanding industrial and commercial applications.
Flexible Socket Configuration:
Offers a range of socket options for connecting various tools and heavy-duty equipment with ease.
Durable Open Type Design:
Built with a robust open-frame structure for enhanced durability and simplified maintenance, especially in challenging environments.
Efficient Fuel Use:
Designed for optimal diesel consumption, providing a reliable and economical energy solution for prolonged operation.
Comprehensive Safety Features:
Incorporates overload protection and a user-friendly control panel to ensure safe and stable performance.
Certified Quality and Compliance:
Comes with CE and EURO V certifications, as well as a noise level certificate for assured safety, quality, and environmental standards.

Specification	Details
Model	TC11000E3D
Generator Type	Diesel Generator 8.5kW Three Phase Open Type
Max Power Output	8.5kW
Rated Power Output	8.0kW
Performance
Generator Description	-Three phase equal power - 230V&400V/50HZ - 3 in 1 digital meter(V/HZ/H) - Key start with 36Ah battery - Alternator size: 204*160mm - 35mm square frame
Fuel Type	Diesel
Fuel Tank Capacity	15 L
Noise Level	≤96 dB (7m@25% load)
Engine Description	- 1100FE - 1 cylinder - Bore&stroke: 100*85mm - Displacement: 667ml - Rated speed: 3000rpm - Rated power: 10.5kw - Max power: 11.0kw
Usability
Starting Method	Electric start
Outlets	1 x single-phase European socket (three-phase equal power) with blue cover (230V 16A) 1 x single-phase Industrial socket (three-phase equal power) with blue cover (230V 32A ) 1 x three phases industrial socket with red cover (400V 32A) DC 12V terminal
Physical
Weight	140 kg
Dimensions	790595725 mm
Additional Features	Wheels and handrail, Three in one digital display meter
Packaging Information
Package Type	Outer carton
Quantity per Carton	1
Package Size	\
Net/Gross Weight	140/150 kg
Certificate	CE/EU V
